GUILLOTINE GLASS SYSTEM
It is an alternative solution for high-rise buildings, restaurants, cafes, hotels, and home owners.
– Since the lowest window in the system can be opened, all windows can be wiped.
– The lenses move horizontally, up and down.
– The system moves with a motor. Button and remote start can be given. Both are applicable.
– 4+16+4 mm tempered glass is used. (The combination can be changed upon request.)
– It provides insulation thanks to 67 x 1200 bristle wicks in the aluminum case on the sides.
– A 20 mm x 25 mm durable strap with rope inside is used to lift the windows up. It ensures quiet operation. (Optionally, it can be used on the chain instead of the belt.)
– There are 8 bearings on each wing. That allows the windows to move easily and takes the gap in the side channels.
– 20 systems can be controlled with a single control. You can stop the windows wherever you want.
– When the system is open, it acts as a glass railing as 3 glasses stand side by side.
– When the system is turned off, it provides sound, heat, and water insulation.
– It is safe. It also does not require locks.
– You can leave it open as much as you want from top to bottom and let the space air without feeling the discomfort of the wind.
GUILLOTINE SYSTEM is designed in R&D with customer satisfaction, quality, and easy installation in mind. Profile design and registration have been patented by TPE.
Ready to See What Your Space Could Look Like?
Get Started
Tell us your dimensions and we'll send you a free 3D rendering. No commitment, no pressure.
We respond within a few hours · (347) 459-0784 · adam@comfortpergola.com
Guillotine Glass System
The remote-controlled Guillotine Glass System turns any outdoor space into a fully enclosed room. Perfect for backyards, patios, and covered decks.
Watch Our Guillotine Glass System in Action
GUILLOTINE GLASS SYSTEM TECHNICAL SPECIFICATION
1) The total internal space of the bases is 24 mm. Optional glass thickness can be changed.
2) Aluminum wall thickness is 2 mm.
3) Optional glass number can be applied as 2 or 3 in the system.
4) Thanks to the durable chain used in the system, the glasses move up and down easily and silently. Optionally, 20 mm x 25 mm durable belt with rope inside can be used.
5) We have 8 steel stainless bearings on our side rails for our windows to go up and down in a balanced way.
6) Optional (LCF, BECKER, CUPON or SOMFY MOTOR) is used in our systems.
7) Our maximum dimensions are 5500 mm in width and 2200 mm in height. Dimensions can be changed as a combination upon request.
8) Thanks to our supported profiles, there is no stretching or shaking.
9) 20 systems can be operated at once with a single remote control.
10) It locks itself when closed and cannot be opened from the outside or inside.
11) Thanks to the additional side rails in our system, in case of any renovation or glass breakage, the renovation process can be easily done without damaging the system and without dismantling the product.
